13
Heavy! Handle with care!!
Warning: when moving the machine, you should have your hands holding on the upper supporting beam
and the rear supporting beam. Do not use roller gap adjustment hand-wheel for lifting!
9 E. Set machine on stand
1. Remove machine from the bottom supports of the packing box
2. Lift machine onto support stand
3. Note two shaft storage brackets on stand are to the rear of the machine
4. Insert anchor bolts through stand into bottom of machine
Shaft storage brackets
Front Rear
