Instructions for use and maintenance
Rev. 11/2013 - EN
3.1 DENOMINATION OF THE COMPONENTS
FIG. 2 shows and contains the denominations of the components making up the oven.
3.2– DIMENSIONS OF OVEN AND BAKING CHAMBER
ELECTRIC OVENS FOR PIZZA
SERIES “E”
FIG.2
(Denomination of the components)
LEGEND:
1) Oven door handle
2) Steam discharge
3) Chamber light
4) Power supply cable
(without plug)
5) Aeration openings
6) Control panel
7) CE marking
8) Inspection glass
9) Oven door
6 9 8 5
2
7
1
4
3
2.2- STATUS OF “TURNED OFF OVEN”
Before performing any type of maintenance and/or adjustment intervention, it is compulsory to
disconnect the power supply source, disconnecting the power supply plug from the mains outlet
verifying that the oven is effectively turned off and cooled.
2.3- WARRANTY
The manufacturer warrants that the concerned ovens are tested at manufacturer’s premises.
The warranty of the oven is of 12 (twelve) months.
2.4- RESERVED RIGHTS
The reserved rights concerning this technical manual, “Use and maintenance instructions” remain
property of the Manufacturer. No part of the manual can be reproduced and disclosed by any
reproduction means without prior written authorization of the Manufacturer.
All quoted trademarks belong to the related owners.
2– GENERAL REMARKS
THE TAMPERING AND/OR REPLACEMENT OF PARTS WITH NON ORIGINAL SPARE PARTS
CAUSE THE DECAY OF THE WARRANTY AND RELEASE THE MANUFACTURER FROM ANY
LIABILITY.
3– TECHNICAL DESCRIPTION
