Page 20
DMX
Mode 8ch
CHANNEL VALUES FUNCTION
1
AUTO MODE
000-010 IDLE
011-050 AUTO 1 : COLORS MACRO
051-100 AUTO 2 : CHASE IN JUMP MODE
101-150 AUTO 3 : CHASE IN PULSE MODE
151-200 AUTO 4 : SOUND MODE
201-255 AUTO 5 : STROBE
2
COLORS MACRO
000-039 RGBW
040-049 RED
050-059 GREEN
060-069 BLUE
070-079 YELLOW
080-089 CYAN
090-099 PURPLE
100-109 WHITE
110-119 RED + GREEN
120-129 RED + BLUE
130-139 RED + WHITE
140-149 GREEN + BLUE
150-159 GREEN + WHITE
160-169 BLUE + WHITE
170-179 RED + GREEN + WHITE
180-189 RED + BLUE + WHITE
190-199 GREEN + BLUE + WHITE
200-209 RED + GREEN + BLUE
210-255 RED + GREEN + BLUE + WHITE
3 000-255 CHASE SPEED
4 000-255 MASTER DIMMER
5 000-255 RED DIMMER
6 000-255 GREEN DIMMER
7 000-255 BLUE DIMMER
8 000-255 WHITE DIMMER
