Giant AC BIKES-2001 - Sizing

- Pag. 3. -
2. Sizing.
The actual frame measurements and geometries are listed below.
Size S - 17” M - 18” L - 19”
A. Top Tube [mm.] (measured horizontally) 565 585 605
B. Seat Tube [mm.] 430 455 480
C. Seat Tube Angle 72 degrees
D. Head Tube Angle 68½ degrees
E. B.B. Drop [mm.] -6
F. Chain stays [mm.] 430
G. Fork Rake [mm.] 43
H. Trail [mm.] 84
I. Wheel Base [mm.] 1100 1115 1135
Rear Travel 6~5¼~4½ ”
Figure 1.
