GiBiDi BA24 Instructions For Installation

32
I
33
UK
BA24 BA24
Ammistratore Delegato
Oliviero Arosio
Dichiarazione di conformità CE
Il fabbricante:
GI.BI.DI.
Via Abetone Brennero, 177/B,
46025 Poggio Rusco (MN) ITALY
Dichiara che i prodotti:
APPARECCHIATURA ELETTRONICA BA24
Sono conformi alle seguenti Direttive CEE:
• Direttiva LVD 2006/95/CE e successive modifiche;
• Direttiva EMC 2004/108/CE e successive modifiche;
e che sono state applicate le seguenti norme armonizzate:
• EN60335-1,EN60335-2-103, EN50366
• EN61000-6-2, EN61000-6-3
Data 10/12/2010
S.r.l.
BA24 / AS05590
Electronic control unit for the automation of one
or two motors – 24V dc – for swinging and sliding gates,
overhead garage doors and barriers
230Vac monophase 50/60 Hz
1 or 2
24 Vdc
24Vdc 10W max
24Vdc 3W max
Control unit
Type
Power supply
N° motors
Motor power supply
Flashing light
Warning light
24Vdc 8W max including safety device power supply
Accessories power supply
24Vcc 8W max including accessories power supply
-20°C +60°C
Plug-in
Safety device power supply
Operating temperature
Radio receiver
TECHNICAL SPECIFICATIONS / FUNCTIONS
• Red warning LEDs of N.C. contacts. There isn't the safety devices LED. See “SIGNALLING LED” table.
• Green warning LEDs of N.A. contacts. See “SIGNALLING LED” table.
• Two electrical locks management.
• Safety test run before the opening and closing movement.
• Photocell 1 test run before the opening and closing movement.
• Amperometric circuit test run before the opening and closing movement.
• Stop and motion inversion for 2 seconds after intervention of the safety devices. At the next START pulse the
motion reSTARTs in the obstacle freeing direction.
• SEPARATE SAFETY DEVICES POWER SUPPLY. Connect the safety devices that must be tested to this
clamp.
• Digital programming of all functions.
• Working time settable independently in opening and closing for each motor.
• Deceleration time settable independently in opening and closing for each motor in the ending motion phase
(soft-stop).
• Gate phase shift time settable independently in opening and closing.
• Settable pedestrian working time.
• Pause time settable and differentiated for complete opening or pedestrian opening.
• Thrust force settable on 10 levels for each motor.
• Decelerations selectable and settable independently on 10 levels for each motor.
• Decelerated departure (soft START) that can be selected in 3 different modes.
• Absorption (anti-crushing) control settable on 100 levels for each motor both in thrust phase and in
deceleration phase.
• Deceleration enabling: with single or double limit switches reading.
• 4 possible working functions (step-by-step, step-by-step with stop, co-ownership's or automatic, dead-man).
• Possibility to choose the equipment configuration among swinging, overhead/barrier and sliding, single or
double.
• SAFETY DEVICE choice with N.C. contact or 8K2 resistive.
• Anti-crushing enabling (motion inversion for 2 seconds and stop) or amperometric detection for limit switch.
