1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) D_LED1
6) LED_C
7) SATA3 0/1/2/3
8) M2A_CPU
9) F_PANEL
10) F_ AUDIO
11) CI
12) SPEAKER
13) F_U32
14) F_USB1/F_USB2
15) COM
16) TPM
17) CLR_CMOS
18) BAT
49 121711
2
7
14 13610
1
15
16
18
5
4
8
3
- 12 -
