- 20 -
2-8 Internal Connectors
1) ATX_12V_2X2/ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3/4
5) SYS_FAN5/6_PUMP
6) CPU_OPT
7) EC_TEMP1/EC_TEMP2
8) D_LED1/D_LED2
9) LED_C1/LED_C2
10) NOISE_SENSOR
11) SATA3 4/5/6/7
12) M2C_CPU/M2A_CPU/M2Q_SB/M2P_SB/M2M_SB
13) F_PANEL
14) F_AUDIO
15) F_U320G
16) F_U32
17) F_USB1/F_USB2
18) COM
19) SPI_TPM
20) THB_C1/THB_C2
21) CLR_CMOS
22) RST
23) BAT
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1321
16
10
12
5
2
7
11
20
15
7 4171814 8 19
1
9
23
22
12
12
12
12
3 8 96
