Quick Installation Guide
8
CPU
SW
1 2 3 4 5 6 7 8
JP7 JP8 JP9
JP1
0
55. IDT Winchip 2-233
(66*3.5 3.5V)
*
X X X O O O O X 2-3 2-3 2-3 1-2
56. IDT Winchip 2-233
(100*2.33 3.5V)
*
X O O O O O O X 1-2 1-2 2-3 1-2
57. IDT Winchip 2-266
(66*4 3.5V)
O X O O O O O X 2-3 2-3 2-3 1-2
58. IDT Winchip 2-266
(100*2.66 3.5V)
*
X X O O O O O X 1-2 1-2 2-3 1-2
59. IDT Winchip 2-300
(100*2.5 3.5V)
*
O O X O O O O X 1-2 1-2 2-3 1-2
60. IDT Winchip 3-266
(100*2.33 2.8V)
*
X O O X X X O X 1-2 1-2 2-3 1-2
61. RISE MP6-266
(100*2 2.8V)
*
O X X X X X O X 1-2 1-2 2-3 1-2
¬Note: If Cyrix 6x86 is being used, please check the CPU Date Code after 605.
M
The default setting is 100*3 at 2.2V for AMD K6/300 and AMD K6-2/300
CPU
SW
1 2 3 4 5 6 7 8
JP7 JP8 JP9
JP1
0
AMD-K6/300 (100*3 2.2V)
AMD-K6-
2/300 (100*3
2.2V)
X O X X O X X X
1-2 1-2 2-3 1-2
M
The settings of the processors marked with “*” above are just for your
reference, these processors have not been tested yet !
