5AX
4-26
4.12. INTEGRATED PERIPHERALS
Figure 4.9: Integrated peripherals
@ When KB PWR ON/OFF Function set Enabled, KB PWR ON/OFF Password :
Enter will show up.
* These three items will show up when RTC Alarm Controller is enabled.
% These two items will show up when Onboard IrDA Port is Assign Available
Address# for IrDA port.
# These two items will show up when IrDA Mode is IrDA 1.1.
• On-Chip Primary IDE
The default value is Enabled.
Enabled Enable onboard 1st channel IDE port.
Disabled Disable onboard 1st channel IDE port.
•
Master PIO (for onboard IDE 1st channel).
The default value is Auto.
Auto BIOS will automatically detect the IDE HDD Accessing
mode.
Mode0~4 Manually set the IDE Accessing mode.
