Quick Installation Guide
4
II. Quick Installation Guide:
O: ON X: OFF
CPU
SW
1 2 3 4 5 6 7 8
JP7 JP8 JP9
JP1
0
1. Pentium

133 MHz
O X X O O O O X 2-3 2-3 2-3 1-2
2. Pentium

166 MHz
O O X O O O O X 2-3 2-3 2-3 1-2
3. Pentium

200 MHz
X O X O O O O X 2-3 2-3 2-3 1-2
4. Intel MMX-166MHz
O O X X X X O X 2-3 2-3 2-3 1-2
5. Intel MMX-200MHz
X O X X X X O X 2-3 2-3 2-3 1-2
6. Intel MMX-233MHz
X X X X X X O X 2-3 2-3 2-3 1-2
7. AMD-K6/166 (2.9V)
O O X O X X O X 2-3 2-3 2-3 1-2
8. AMD-K6/200 (2.9V)
X O X O X X O X 2-3 2-3 2-3 1-2
9. AMD-K6/233 (3.2V)
X X X X X O O X 2-3 2-3 2-3 1-2
10.AMD-K6/233 (66*3.5 2.2V)
X X X X O X X X
2-3 2-3 2-3 1-2
11. AMD-K6/266 (66*4 2.2V)
AMD-K6-2/266 (66*4 2.2V)
O X O X O X X X
2-3 2-3 2-3 1-2
12. AMD-K6/300 (66*4.5 2.2V)
O O O X O X X X
2-3 2-3 2-3 1-2
13. AMD-K6/300 (100*3 2.2V)
AMD-K6-2
/300 (100*3
2.2V)
X O X X O X X X
1-2 1-2 2-3 1-2
14. AMD-K6-2/333 (66*5 2.2V)
X O O X O X X X
2-3 2-3 2-3 1-2
15. AMD-K6-
2/333 (95*3.5
2.2V)
X X X X O X X X 1-2 1-2 2-3 2-3
16. AMD-K6-
2/350 (100*3.5
2.2V)
X X X X O X X X
1-2 1-2 2-3 1-2
17.AMD-K6-
2/366 (66*5.5
2.2V)
*
X X O X O X X X 2-3 2-3 2-3 1-2
18. AMD-K6-2/380 (95*4 2.2V)
O X O X O X X X 1-2 1-2 2-3 2-3
19. AMD-K6-2/400 (100*4
2.2V)
O X O X O X X X 1-2 1-2 2-3 1-2
20. AMD-K6-2+/450 (100*4.5
2.2V)*
O O O X O X X X 1-2 1-2 2-3 1-2
21. AMD-K6-2/450 (100*4.5
2.2V)
O O O X O X X X 1-2 1-2 2-3 1-2
22. AMD-K6-2/450 (100*4.5
2.4V)
O O O X X O X X 1-2 1-2 2-3 1-2
23. AMD-K6-2/475 (95*5 2.2V)
* X O O X O X X X 1-2 1-2 2-3 2-3
24. AMD-K6-2/475 (95*5 2.4V)
* X O O X X O X X 1-2 1-2 2-3 2-3
25. AMD-K6-2/500 (100*5
2.2V)
*
X O O X O X X X 1-2 1-2 2-3 1-2
