Quick Installation Guide
6
CPU
SW
1 2 3 4 5 6 7 8 JP7 JP8 JP9
JP1
0
33. AMD-K6-III/475 (95*5
2.4V)
*
X O O X X O X X
1-2 1-2 2-3 2-3
34. AMD-K6-III/500 (100*5
2.2V)
*
X O O X O X X X 1-2 1-2 2-3 1-2
35. AMD-K6-III/500 (100*5
2.4V)
*
X O O X X O X X 1-2 1-2 2-3 1-2
36. AMD-K6-III/550
(100*5.5 2.2V)
*
X X O X O X X X 1-2 1-2 2-3 1-2
37. Cyrix/IBM 6x86MX-PR166
(66*2 2.9V)
O X X O X X O X
2-3 2-3 2-3 1-2
38. Cyrix/IBM 6x86MX-PR200
(66*2.5 2.9V)
O O X
O X X O X
2-3 2-3 2-3 1-2
39. Cyrix/IBM 6x86MX-PR200
(75*2 2.9V)
O X X
O X X O X
1-2 2-3 2-3 2-3
40. Cyrix/IBM 6x86MX-PR233
(66*3 2.9V)
X O X
O X X O X
2-3 2-3 2-3 1-2
41. Cyrix/IBM 6x86MX-PR233
(75*2.5 2.9V)
O O X
O X X O X
1-2 2-3 2-3 2-3
42. Cyrix/IBM 6x86MX-PR233
(83*2 2.9V)
O X X
O X X O X
1-2 2-3 2-3 1-2
43. Cyrix/IBM 6x86MX-PR266
(66*3.5 2.9V)
X X X
O X X O X
2-3 2-3 2-3 1-2
44. Cyrix/IBM 6x86MX-PR266
(75*3 2.9V)
X O X O X X O X 1-2 2-3 2-3 2-3
45. Cyrix/IBM 6x86MX-PR266
(83*2.5 2.9V)
O O X
O X X O X
1-2 2-3 2-3 1-2
46. Cyrix MII-300
(66*3.5 2.9V)
X X X
O X X O X
2-3 2-3 2-3 1-2
47. Cyrix MII-PR333
(66*4 2.9V)
O X O
O X X O X
2-3 2-3 2-3 1-2
48. Cyrix MII-PR333
(83*3 2.9V)
X O X
O X X O X
1-2 2-3 2-3 1-2
49. Cyrix MII-PR333
(75*3.5 2.9V)
X X X
O X X O X
1-2 2-3 2-3 2-3
50. Cyrix MII-PR366
*
(100*2.5 2.9V)
O O X O X X O X 1-2 1-2 2-3 1-2
51. Cyrix MII-PR400
*
(100*3 2.9V)
X X X O X X O X 1-2 1-2 2-3 1-2
52. IDT Winchip 2-200
(66*3 3.5V)
X O X O O O O X 2-3 2-3 2-3 1-2
