5AX
4-28
• Slave PIO (for onboard IDE 2nd channel).
The default value is Auto.
Auto BIOS will automatically detect the IDE HDD Accessing
mode.
Mode0~4 Manually set the IDE Accessing mode.
• Master Ultra DMA (for onboard IDE 2nd channel).
The default value is Auto.
Auto BIOS will automatically detect the IDE HDD Accessing
mode.
Disabled Disable UDMA function.
• Slave Ultra DMA (for onboard IDE 2nd channel).
The default value is Auto.
Auto BIOS will automatically detect the IDE HDD Accessing
mode.
Disabled Disable UDMA function.
• IDE HDD Block Mode
The default value is Enabled.
Enabled Enable IDE HDD Block Mode
Disabled Disable IDE HDD Block Mode
•
On-Chip USB Controller
The default value is Enabled.
Disabled Disable USB Controller.
Enabled Enable USB Controller.
•
USB Keyboard Support
The default value is Disabled.
Disabled Disable USB Keyboard Support.
Enabled Enable USB Keyboard Support.
