- 8 -
G1.Sniper 3 Motherboard Block Diagram
For detailed product information/limitation(s), refer to "1-2
Product Specications."
or
1 PCI
PS/2 KB/Mouse
LGA1155 CPU
Intel
®
Z77
iTE
Super
I/O
CPU CLK+/- (100 MHz)
Dual BIOS
LPC
Bus
DDR3 1600/1333/1066 MHz
4 USB 2.0/1.1
2 SATA 6Gb/s
Dual Channel Memory
VIA VL810
Hub
8 USB 3.0/2.0
VIA VL810
Hub
Center/Subwoofer Speaker Out
Line Out
MIC/Line In
S/PDIF Out
Surround Speaker Out
CREATIVE
CA0132
x1
3 SATA 3Gb/s
PCIe to PCI Bridge
x1
PCI Bus
PCI CLK
(33 MHz)
VIA VT6308
2 IEEE 1394a
PCIe CLK
(100 MHz)
PCI Express Bus
1 PCI Express x16
2 PCI Express x8
PEX8747
x8
x16
Switch
1 PCI Express x16
x16
Switch
2 PCI Express x8
x8
D-Sub
DVI-D
HDMI
DisplayPort
DMI 2.0
FDI
Switch
1 SATA 3Gb/s
1 mSATA
2 USB 3.0/2.0
HP Out
PCI Express Bus
PCIe CLK
(100 MHz)
x1
x1
LAN 2
RJ45
Intel GbE LAN phy
Marvell
88SE9172
2 SATA 6Gb/s
x1
2 SATA 6Gb/s
PCI Express Bus
2 PCI Express x1
x1x1
PCIe CLK
(100 MHz)
Marvell
88SE9172
x1
LAN 1
RJ45
Qualcomm Atheros Killer
E2201 LAN
