Hardware Installation - 12 -
Internal I/O
1 x TPM header
1 x Front panel header
Front I/O 2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD access LED
Rear I/O
N/A
Backplane I/O 6 x 2.5" NVMe/ SATA hybrid ports
Speed and bandwidth: PCIe Gen4 or SATA 6Gb/s
TPM 1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Power Supply 3+1 x 3000W redundant PSUs
80 PLUS Platinum
AC Input:
- 115-127V~/ 14.2A, 50-60Hz
- 200-240V~/ 15.8A, 50-60Hz
DC Input:
240Vdc/ 14A
DC Output:
- Max 1200W/ 100-127V~
+54V/ 95.6A
+12Vsb/ 3.5A
- Max 3000W/ 200-240V~
+54V/ 178.1A
+12Vsb/ 3.5A
NOTE: The system power supply requires C19 type power cord
