Gigabyte G492-ZD2 User Manual

Hardware Installation - 14 -
1-3 System Block Diagram
G492-ZD2 System Block Diagram
8-Channel DDR4, 16 x DIMMs
Speed up to 3200 MHz
4 x PCIe x16 slots
(rear side)
PCIe x16 slot
(front side, support MD2 card)
PCIe x16 slot
(front side, support MD2 card)
8-Channel DDR4, 16 x DIMMs
Speed up to 3200 MHz
xGMI2 18GT/s
x4 Link
BIOS
TPM
2 x 10GbE
BASE-T LAN
2 x USB 3.0
MLAN
VGA
eSPI WAFL x1 USB2.0 x2 USB3.0 x2
ASPEED
AST2500
10/100/1G
PHY(1ch)
MAC
BMC
PCIe3.0x4
Intel
X710-AT2
SATA III x8
PCIe4.0 x16
NVMe x1 NVMe x2
SPI
PCIe4.0 x16
PCIe4.0 x16 NVMe x1 NVMe x2 PCIe4.0 x16
6-bay 2.5” Gen4 U.2 NVMe/ SATA
PCIe4.0 x16 PCIe4.0 x16
4 x PCIe x16 slots
(rear side)
CPU0
ROME / MILAN
“Zen3” Core
Socket SP3
PCIe Switch
PEX88096
PCIe Switch
PEX88096
PCIe Switch
PEX88096
PCIe Switch
PEX88096
CPU1
ROME / MILAN
“Zen3” Core
Socket SP3
NVIDIA HGX A100 8-GPU
NVIDIA HGX A100 8-GPU
(Delta Baseboard)
(Delta Baseboard)
NVIDIA HGX A100 8-GPU
(Delta Baseboard)
SPI Flash 32MB
Front Panel
PCIe4.0x4
PCIe4.0x4
M.2
M.2
CMTP062
(rear side)
