GA-965P-DS3P Motherboard - 68 -

English

(3) Configuring RAID set in RAID BIOS

Enter the RAID BIOS setup utility to configure a RAID array. Skip this step and proceed to Section 4 if

you do not want to create RAID.

Step 1:

After the POST memory test begins and before the operating system boot begins, look for a message

which says "Press <Ctrl-I> to enter Configuration utility" (Figure 3). Press CTRL+ I to enter the RAID

BIOS setup utility.

Figure 3

Step 2:

After you press CTRL+ I, the Create RAID Volume screen will appear (Figure 4).

Create RAID Volume

If you want to create RAID array, select Create RAID Volume in Main Menu and press ENTER.

Figure 4

Intel(R) Matrix Storage Manager option ROM V6.0.0.1022 ICH8R wRAID5

[ MAIN MENU ]

1.Create RAID Volume

2. Delete RAID Volume

3. Reset Disks to Non-RAID

4. Exit

[ DISK/VOLUME INFORMATION ]

RAID Volumes :

None Defined.

Physical Disks :

Port Driver Model Serial # Size Type/Status(Vol ID)

0 ST3120026AS 3JT354CP 111.7GB Non-RAID Disk

1 ST3120026AS 3JT329JX 111.7GB Non-RAID Disk

[]-Select [ESC]-Exit [ENTER]-Select Menu
