- 13 -
1-7 Back Panel Connectors
PS/2 Keyboard and PS/2 Mouse Port
Usetheupperport(green)toconnectaPS/2mouseandthelowerport(purple)toconnectaPS/2keyboard.
D-Sub Port
The D-Sub port supports a 15-pin D-Sub connector. Connect a monitor that supports D-Sub connection
to this port.
DVI-D Port
(Note)
TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof2560x1600.
Connect a monitor that supports DVI-D connection to this port. Please note that the actual resolutions
supported are dependent on the monitor being used and support for 2560x1600 resolution requires both
a monitor and cable that support Dual Link DVI.
USB 2.0/1.1 Port
TheUSBportsupportstheUSB2.0/1.1specication.Usethisport for USB devices such as a USB
keyboard/mouse,USBprinter,USBashdriveandetc.
RJ-45LANPort
The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following
describes the states of the LAN port LEDs.
(Note) TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.
Activity LED
Connection/
Speed LED
LAN Port
Connection/Speed LED:
State Description
Orange 1 Gbps data rate
Green 100 Mbps data rate
Off 10 Mbps data rate
Activity LED:
State Description
Blinking Data transmission or receiving is occurring
Off No data transmission or receiving is occurring
LineInJack(Blue)
Thedefaultlineinjack.Usethisaudiojackforlineindevicessuchasanopticaldrive,walkman,etc.
LineOutJack(Green)
Thedefaultlineoutjack.Usethisaudiojackforaheadphoneor2-channelspeaker.Thisjackcanbeused
toconnectfrontspeakersina4/5.1/7.1-channelaudioconguration.
MicInJack(Pink)
ThedefaultMicinjack.Microphonesmustbeconnectedtothisjack.
Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour
device and then remove it from the motherboard.
When removing the cable, pull it straight out from the connector. Do not rock it side to side to prevent
an electrical short inside the cable connector.
Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomoduleandenablethe
multi-channel audio feature through the audio driver.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte GA-F2A55M-DS2 and is the answer not in the manual?

Gigabyte GA-F2A55M-DS2 Specifications

General IconGeneral
Memory voltage1.5 V
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds1066, 1333, 1600, 1866 MHz
Processor socketSocket FM2
Processor manufacturerAMD
Compatible processor seriesAMD A
Maximum number of SMP processors1
S/PDIF out connectorYes
Number of SATA II connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chipRealtek ALC887
Cooling typePassive
Component forPC
Power source typeATX
Motherboard chipsetAMD A55
Audio output channels7.1 channels
Motherboard form factormicro ATX
RAID levels0, 1, 10, JBOD
Supported storage drive interfacesSATA II
PCI Express slots version2.0
PCI Express configurations1x1, 1x16
Graphics cardRadeon HD 7000
DirectX version11
Maximum resolution2560 x 1600 pixels
Parallel processing technology supportNot supported
Trial softwareNorton Internet Security
Cables includedSATA
Ethernet interface typeGigabit Ethernet
BIOS typeAMI
ACPI version2.0a
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth174 mm
Width225 mm
