Page #11 background imageLoading...
Page #11 background image
- 11 - Hardware Installation
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATA 6Gb/s connectors
2 x SATA 3Gb/s connectors
1 x USB 3.0/2.0 header
1 x USB 2.0/1.1 header
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x serial port header
1 x S/PDIF Out header
1 x Clear CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
2 x HDMI ports
2 x antenna connectors
1 x DVI-I port
2 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
2 x RJ-45 ports
1 x optical S/PDIF Out connector
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
Line Out, Mic In)
I/O Controller iTE I/O Controller Chip
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU fan speed control
* Whether the CPU fan speed control function is supported will depend on the CPU
cooler you install.
BIOS [0ELWÀDVK
Use of licensed AMI EFI BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a

Other manuals for Gigabyte GA-H77N-WIFI

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Gigabyte GA-H77N-WIFI and is the answer not in the manual?

Gigabyte GA-H77N-WIFI Specifications

General IconGeneral
Memory voltage1.5 V
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds800, 1066, 1333, 1600 MHz
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
CPU fan connectorYes
Number of Parallel ATA connectors0
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 2.0 ports quantity4
Audio chipRealtek ALC892
Component forPC
Power source typeATX
Motherboard chipsetIntel H77
Audio output channels7.1 channels
Motherboard form factormini ITX
Compatible operating systemsWindows 8/7/XP
Supported storage drive interfacesSATA II, SATA III
Parallel processing technology support-
Networking featuresGigagit Ethernet, WLAN
Ethernet interface typeGigabit Ethernet
BIOS typeEFI AMI
Bundled softwareNorton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology
Weight and Dimensions IconWeight and Dimensions
Width170 mm
