Unique Features - 74 -
Step 5:
7KHFRQ¿UPDWLRQPHVVDJHZLOODOVRDSSHDURQWKHWDUJHW
FRPSXWHUDVNLQJZKHWKHUWRDFFHSWWKH¿OHIROGHUIURP
the source computer. Click YesWRFRQ¿UP<RXPXVW
respond in 15 seconds. The RX light will be on when
WKH¿OHGDWDLVEHLQJUHFHLYHG
Step 6:
The data will be automatically stored to a folder in
the My Documents\AirFileDownloads directory in
the target computer, which is named according to the
receiving time. To directly access this directory later,
you can also right-click the Wi-Fi Share icon in the
QRWL¿FDWLRQDUHDDQGVHOHFWLocal Shared Directory.
C. Wi-Fi Mode Only
In this mode, the Wi-Fi/Bluetooth card is set as a normal wireless LAN card and needs to connect to a wireless
access point to get Internet connection.

Gigabyte GA-H77N-WIFI Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
CPU fan connector	Yes
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Compatible operating systems	Windows 8/7/XP
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	-
Networking features	Gigagit Ethernet, WLAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
Bundled software	Norton Internet Security (OEM version), Intel Rapid Start Technology, Intel Smart Connect Technology, Intel Smart Response Technology

Weight and Dimensions

Width	170 mm
