Gigabyte GA-Z97P-D3 User Manual

- 8 -
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 3 x system fan headers
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 6 x SATA 6Gb/s connectors
 1 x USB 3.0/2.0 header
 3 x USB 2.0/1.1 headers
 1 x serial port header
 1 x parallel port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 1 x serial port
 1 x HDMI port
 2 x USB 3.0/2.0 ports
 4 x USB 2.0/1.1 ports
 1 x RJ-45 port
 
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 System voltage detection
 CPU/System temperature detection
 CPU/System fan speed detection
 CPU/System overheating warning
 CPU/System fan fail warning
 CPU/System fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  
 Use of licensed AMI UEFI BIOS
 Support for DualBIOS
™
 PnP 1.0a, DMI 2.7, SM BIOS 2.7, ACPI 2.0
Unique Features  Support for APP Center
* Available applications in APP Center may differ by motherboard model. Supported

- @BIOS
- EasyTune
- EZ Setup
- Fast Boot
- ON/OFF Charge
- Smart TimeLock
- Smart Recovery 2
- System Information Viewer
- USB Blocker
 Support for Q-Flash

Gigabyte GA-Z97P-D3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400, 2600, 2666, 2800, 2933, 3000 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	3
Number of SATA connectors	6
Number of SATA II connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel® Z97
Audio output channels	7.1 channels
Motherboard form factor	ATX
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	1000 MB
Parallel processing technology support	2-Way CrossFireX
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit

Weight and Dimensions

Depth	200 mm
Width	305 mm
