- 10 -
Hardware Installation
Socket
Socket
Security
Security
Expansion Slots Slot_6: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU
Slot_5: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU
Slot_4: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU
Slot_3: 1 x PCIe x16 (Gen5 x16 bus) slot, from CPU
Slot_2: 1 x PCIe x16 (Gen5 x16 or x8 bus) slot, from CPU, shared with Slot_1
Slot_1: 1 x PCIe x8 (Gen5 x8 bus) slot, from CPU
1 x M.2 slot:
- M-key
- PCIe Gen3 x4 per slot, from PCH
- Supports 2280 cards
Socket
Socket
Security
Security
Internal I/O
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x M.2 slot
1 x CPU fan headers
7 x System fan headers
2 x USB 3.2 Gen1 headers
2 x USB 2.0 headers
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x HDD backplane board header
1 x PMBus connector
1 x IPMB connector
1xClearCMOSjumper
1xBIOSrecoveryjumper
1 x Buzzer
Socket
Socket
Security
Security
Rear I/O
Connectors
2 x USB 3.2 Gen1
1 x VGA
1 x COM
6 x RJ45
1 x MLAN
1 x ID button with LED
Socket
Socket
Security
Security
TPM
1 x TPM Header with SPI Interface
Optional TPM2.0 kit: CTM010
Socket
Socket
Security
Security
