Gigabyte MS03-6L0 User Manual

- 18 -
Hardware Installation
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX1 12) FP_1
2) P12V_AUX1 13) BP_1
3) P12V_AUX2 14) COM2
4) SATA_4_5 15) SPI_TPM
5) SATA_SGP2 16) IPMB
6) SW_RAID 17) CN_NCSI
7) CPU0_FAN 18) F_AUDIO1
8) SYS_FAN1/2//3
/
4/5/6 19) GPIO_CNT_1/GPIO_CNT_2
9) PMBUS 20) LED_BMC
10) F_USB1 21) BAT
11) F_USB2 22) CASE_OPEN
DIMM_P0_D0 DIMM_P0_C0 DIMM_P0_B0 DIMM_P0_A0 DIMM_P0_H0 DIMM_P0_E0 DIMM_P0_F0 DIMM_P0_G0
CPU0
20
8
11
18
21
1
2
3
4
5
6
7
88
9
10
12
13
14
15
16
17
19
22
