Gigabyte MS03-6L0 User Manual

- 6 -
Item Code Description
1 LED_BMC BMC Firmware Readiness LED
2 F_AUDIO1 Front Audio Header
3 USB3_MLAN Server Management LAN Port (Top)/USB 3.2 Gen1 Ports (Bottom)
4 10G_LAN1_2 10GbE LAN Port #1/#2
5 LAN_3_4 1GbE LAN Port #3/#4
6 LAN_5_6 1GbE LAN Port #5/#6
7 COM1_VGA Serial Port (Top)/VGA Port (Bottom)
8 SW_ID ID Button with LED
9 SYS_FAN6 System Fan Connector #6
10 P12V_AUX1 2x4 Pin 12V Power Connector
11 CPU0_FAN CPU Fan Connector
12 P12V_AUX2 2x4 Pin 12V Power Connector
13 PMBUS PMBus Connector
14 ATX1 2x12 Pin Main Power Connector
15 SYS_FAN5 System Fan Connector #5
16 M2_0 M.2 Slot (PCIe Gen3 x4, Support NGFF-2280)
17 F_USB2 Front USB 2.0 Header
18 SATA_SGPIO SATA SGPIO Connector
19 SATA_4_5 SATA 6Gb/s Connector #4/#5
20 SL_SATA1 Slimline Connector (SATA 6Gb/s Signal)
21 SYS_FAN4 System Fan Connector #4
22 SYS_FAN2 System Fan Connector #2
23 SYS_FAN1 System Fan Connector #1
24 SYS_FAN3 System Fan Connector #3
25 F_USB1 Front Panel USB 3.2 Gen1 Connector
26 FP_1 Front Panel Header
27 SPI_TPM TPM Connector
28 SW_RAID VROC Module Connector
29 BP_1 HDD Backplane Board Connector
30 GPIO_CNT_1 GPIO Connector #1
31 GPIO_CNT_2 GPIO Connector #2
32 COM2 Serial Port Cable Connector
33 IPMB IPMB Connector
34 CN_NCSI NCSI Connector
35 PCIE_1 PCIe x16 Slot #1 (Gen5 x8)
36 PCIE_2 PCIe x16 Slot #2 (Gen5 x16)
37 PCIE_3 PCIe x16 Slot #3 (Gen5 x16)
38 PCIE_4 PCIe x16 Slot #4 (Gen5 x16)
39 PCIE_5 PCIe x16 Slot #5 (Gen5 x16)
40 CASE_OPEN Case Open Intrusion Alert Header
41 PCIE_6 PCIe x16 Slot #6 (Gen5 x16)
42 BAT Battery Socket

Gigabyte MS03-6L0 Specifications

General

Brand	Gigabyte
Model	MS03-6L0
Category	Motherboard
Language	English
