1-2 ProductSpecications
CPU Support for Intel
®
Core
™
i7, Core
™
i5, Core
™
i3 processors/Intel
®
Pentium
®
processors in the LGA1155 package
Support Up to 65W
L3 cache varies with CPU
Chipset Intel
®
H61 Express chipset
Memory Dual channel SODIMM DDR3
Support for DDR3 1333/1066 MHz memory modules
Support Up to 4GB
Audio Realtek ALC887 codec
High Denition Audio
2/4/5.1-channel
LAN 1 x Realtek RTL8111E-VL-CG supports 10/100/1000 Mbps
Expansion Slots 1 x Mini PCI Express slot
Onboard
Graphics
Build in Intel
®
processor
Storage Interface 2 x SATA 3Gb/s connectors
USB 2 x USB 3.0 ports (back panel)
2 x USB 2.0 ports (back panel)
1 x USB 2.0 connector (2 via the USB brackets connected to the internal USB
headers)
Internal
Connectors
2 x SATA 3Gb/s connectors
1 x HDD power connector
1 x CPU fan header
1 x front panel header
1 x audio header
2 x USB 2.0 headers
1 x Speaker header
1 x LVDS connector
1 x FPD connector
1 x Web CAM connector
Back Panel
Connectors
1 x DC-IN
1 x RJ-45 port
1 x HDMI port
2 x USB 3.0 ports
2 x USB 2.0 ports
1 x SPDIF port
1 x Audio Line In
