Item Code Description
1 SPEK Speaker cable connector
2 LINE_IN Audio Line In port
3 SPDIF Optical S/PDIF Out connector
4 R_USB2 USB 3.0 ports
5 R_USB1 USB 2.0 ports
6 HDMI HDMI port
7 LAN1 RJ45 LAN port
8 DC_IN DC In power connector
9 MIN_PCIE1 Mini PCi Express connector
10 BAT1 Battery socket
11 CLR_CMOSHW Clear CMOS jumper
12 F_PANEL Front panel cable connector
13 SATA1/SATA2 SATA cable connectors
14 HDD_PWR Hard disk power connector
15 F_USB1 USB connector
16 F_AUDIO1 Audio cable connector
17 CPU1 Intel LGA1155 socket
18 CPU_FAN CPU fan cable connector
19 FPD Flat Panel Display connector
20 LVDS LVDS connector
21 DMIC_CON Digital Mic connector
22 WEB_CON WEBCAM connector
23 SODIMMB1 DDR3 SO-DIMM slot (channel B-1 )
24 SODIMMA1 DDR3 SO-DIMM slot (channel A-1 )
