BIOS Setup - 44 -
Parameter
Description
Legacy Console Redirection
Legacy Console Redirection
Settings
Press[Enter]tocongureadvanceditems.
Redirection COM Port
– Selects a COM port for Legacy serial redirection.
– Options available: COM1/Serial Over LAN, COM2. Default setting
is COM1/Serial Over LAN.
Resolution
– Selects the number of rows and columns used in Console
Redirection for legacy OS support.
– Options available: 80x24, 80x25. Default setting is 80x24.
Redirect After POST
– When Bootloader is selected, then Legacy Console Redirection
is disabled before booting to legacy OS. When Always Enable is
selected, then Legacy Console Redirection is enabled for legacy
OS.
– Options available: Always Enable, BootLoader. Default setting is
Always Enable.
Serial Port for Out-of-Band
Management / Windows
Emergency Management
Services (EMS) Console
Redirection
(Note)
EMSconsoleredirectionallowstheusertocongureConsoleRedirection
Settings to support Out-of-Band Serial Port management.
Options available: Enabled/Disabled. Default setting is Disabled.
Serial Port for Out-of-Band
EMS Console Redirection
Settings
Press[Enter]tocongureadvanceditems.
Please note that this item is congurable when Serial Port for Out-of-
Band Management EMS Console Redirection is set to Enabled.
Out-of-Band Mgmt Port
– Microsoft Windows Emergency Management Service (EMS) allows
for remote management of a Windows Server OS through a serial
port.
– Options available: COM1/Serial Over LAN, COM2. Default setting
is COM1/Serial Over LAN.
Terminal Type
– Selects a terminal type to be used for console redirection.
– Options available: VT100, VT100Plus, ANSI , VT-UTF8. Default
setting is VT100Plus.
Bits per second
– Selects the transfer rate for console redirection.
– Options available: 9600, 19200, 38400, 57600, 115200. Default
setting is 115200.
(Note) Advanceditemspromptwhenthisitemisdened.
