Gigabyte R152-ZE0 User Manual

- 15 - Hardware Installation
1-3 System Block Diagram
mini-DP
PCIe4.0 x 4
PCIe4.0 x 4
M.2
M.2
PCIe4.0 x 8
PCIe4.0
x 16
PCIe4.0
x 16
8 x SATAIII
Riser CMTP182
2 x SlimLine
2 x SlimLine
2-bay 2.5" U.2/SATA
8-Channel DDR4, 8 x DIMMs
Speed up to 3200 MHz
2 x PCIe x16 FHFL slots
(support 1 x DW GPU or 2 x SW GPUs)
1 x PCIe x16 LPHL slot
Riser CRSE020
Riser CRSH01H
PCIe4.0 x 16
PCIe4.0
x 16
1 x PCIe x16 LPHL slot
Riser CRSH01E
PCIe4.0 x16
PCIe2.0 x2
PCIe2.0 x1
USB2.0 x1
OCP 3.0 mezzanine
Switch
NCSI
NCSI
NCSI
Intel
i350-AM2
2 x 1G LAN
Flash
512 MB
TPM
USB3.0 / USB2.0 x2
2 x USB 3.0
AMD MILAN
“Zen3” Core
Socket SP3
MUX
MLAN
RGMII
10/100/1G
PHY
USB2.0 x1 USB2.0 x1
USB HUB
GL850G
ASPEED
AST2600
BMC
Flash
32 MB
