- 39 - System Hardware Installation
3-10 Replacing the Power Supply
Follow these instructions to replace the power supply:
1. Press the retaining clip on the right side of the power supply along the direction of the arrow.
2. Pull up the power supply handle at the same time and pull out the power supply.
3. Insert the replacement power supply rmly into the chassis. Connect the AC power cord to the
replacement power supply.
3
1
2
