Connecting the telephone
4
3
2
2
5
4
1
¤ Guide the cable through the
cable channel of the handset
cradle: upwards for operat-
ing the phone on the table
(2);
downwards when mount-
ing the phone on the wall
(3).
Wall mounting
¤ Drill two dowel holes into the wall at
a vertical distance of 85 mm and fix
two screws.
¤ Lift out the handset bracket (4) with a
screwdriver and clip it into the handset
cradle (5).
¤ Hang the telephone on the projecting
screw heads.
Please note: The handset bracket must be
placed in the cradle with the slanting edge
facing forwards (see graphic), as otherwise
the handset will not be properly secured.
¤ Connect your telephone to the main phone socket
using the supplied telephone cable and, if necessary,
one of the telephone adapters provided.
¤ Plug the coiled end of the
cable into the handset (1).
