GILCREST PavMaster 314 - Page 32

27
Item .Q t y Description Part # Pg.#
1
2
7
5
6
Note: Right and Left sides are identical.
4
Boggie Wheel Assembly, Pneumatic
1
2
3
4
5
6
7
9104010
9253972
9253908
7566342
4889010/9990031
9955413
7962294
7721749
Boggie Weldment
Axle Pneumatic
Bearing Retainer
Hex Jam Nut 1"
Pneumatic Wheel
Hex Jam Nut 1"
Washer Lock
Bolt 5/8"-11x1 HHCS
1
2
8
4
4
4
4
4
3
