GILCREST PavMaster 314 - Screed Weldment Assembly

41
1
2
3
4
5
6
7
8
1
1
2
1
4
4
2
12
2
2
2
1
1
Screed Weldment LH
Screed Weldment RH
Replaceable Screed Nose
Front Spanner Plate
Screed Tube Flange
Guide Tube Retaining Ring (not shown)
HHCS G5P 5/8"-11 x 7"
Washer Flat 5/8" USS PLTD
Washer Lock 5/8" PLTD
Hex Nut 5/8"-11 PLTD
413 Single Step
Spanner Plate Rear Out
Spanner Plate Inner
9980110
9980111
9557114
9283040
9437100
7698000
7721775
7958294
7962294
7569214
9852901
9283020
9283021
Screed Weldment Assembly
Item . Qty Description Part # Pg.#
1
2
3
4
5
6
7
8
