GILCREST PavMaster 314 - Screed Lift Bracket Assembly 9136200

31
Item .Q t y Description Part #
Screed Lift Bracket Assembly
4
1
2
3
5
6
7
1 1 413 Hopper Weldment 9980400
2 1 Screed Lift Bracket 9136200
3 2 Screed Pin Arm Hook-Up 9636002
4 3 Anchoring Pin 9636000
3 HHCS 5/16"-18x1-1/4" 7721525
3 Washer Flat 5/16" 7962254
5 1 Top Anchor Pin, Wing Cylinder 9636102
6 1 Screed Lift Cylinder 3220342
7 1 Screed Lift Arm 9029400
