GILCREST PavMaster 314 - Page 52

47
Item . Qty Description Part #
1
2
3
4
5
6
7
8
9
1
1
1
1
1
1
1
1
1
2
1
9907113
9907112
9093300
9093301
9250011
9250012
3549752
9860200
9183101
9908010
9636568
Screed Extention Tube-Top LH
Screed Extention Tube-Bottom LH
Bolt-Up End Blade LH
Bolt-Up End Blade RH (not shown)
Standard Screed Ext. End LH
Standard Screed Ext. End RH (not shown)
Auger Motor
Auger Limit Switch
Tube Clamp
Auger Motor Tube
Roll Pin 3/8" x 1 3/4
NOTE: Left and Right Hand Assemblies Are Identical.
1
4
5
6
7
8
9
2
3
Blade Assembly
