Fuel tank Plastic, 8.5 l tank (estimated value)
including the fuel reserve ~ 1.7 l
Front suspension hydraulic double-acting telescopic
fork with 35 mm stems
Front brake Ø 240 mm disc brake (vehicle
LHS), with hydraulic control
activated by handlebar right lever.
Front tyre Tubeless 120/70-14'' 55P
Rear suspension With coaxial spring and hydraulic
shock absorber. Chassis to engine
support with swinging arm.
Rear brake Ø 220 mm disc brake with twin
plunger callipers, hydraulically
controlled by a handlebar lever on
the left side.
Rear tyre Tubeless 140/60-13'' 63P
Wheels Light alloy rims:
FRONT 3.00 x 14"
REAR 3.50 x 13"
Exhaust muffler Absorption type, with a catalytic
converter and a system of air
intake to reduce polluting
emissions.
Chassis Modular double cradle frame made
of welded tubular steel with sheet
metal reinforcement.
Total weight unloaded: 129 Kg
