INSTRUCTIONS FOR USE
The operating and maintenance instructions found in this manual should be followed to ensure years of
reliable service.
Please read these instructions carefully before using the product and keep them in a safe place for
future or use reference.
INTENDED USE AND PRODUCT INFORMATIONS
The Otoscope has universal ttings, which allow a myriad of attachment to be used for Aural and nasal
examination. These Otoscopes are extremely helpful in examining the external acoustic duct and the
tympanic membrane. This instrument recommended for use by medically qualied personnel. Otoscope
is equipped with a rheostat to adjust the intensity of light. The product is equipped with 3 autoclavable
ear cannulas Ø 2.5, 3.5 ,4.5 mm.
An adapter can be also supplied to install a disposable alligator speculum (cod. 31494), suitable to
examine children.
Note: The product or its components cannot be used for purpose different from the one specied in the
present manual. It is not conceived for the employment in operation room.
Due to its powerful luminous intensity, it is advisable not to directly point it at eyes.Do not use
the equipment in case it is damaged. Avoid precarious repairs. Repairs shall be carried out with original
spare parts only, which shall be installed according to the intended use.
Before using, thoroughly check the product and accessories (if provided) the same operation shall be
carried out after cleaning.
This product is equipped with an easy to use Bayonet Locking System. This product is powered by two
1.5 V "C" type alkaline batteries.
INSTALLATION
- Before using it, it is necessary to insert the batteries into the Handle compartment.
Proceed as follows:
- Open the battery compartment. To do this, turn the end cap counter clockwise.
- Once opened, insert the batteries paying attention to the direction of poles (see picture).
- To close the battery compartment, screw down the cap clockwise and check that the batteries are in
contact with poles.
For Operating otoscope / ophtalmoscope with bayonet locking system proceed as follows:
- It is necessary to hold the handle and head in each hand and turn the head counter-clockwise until a
click is heard. At this point it is possible to take the head off.
- To re-attach the head, match the bayonet grooves on both the head and handle, push the head down
and turn the head clock wise.
The operation necessary to remove and replace the speculum is very simple:
- Turn the speculum counter clockwise and draw it out of its seat.
- To re-attach the speculum, insert it into the speculum mount by matching the grooves with the small
pivot and turn clockwise.
CURVED ILLUMINATOR
Various attachments such as mirrors and tongue depressors can be attached to the curved illuminator.
HANDLES
Battery handles contain Rheostats. To turn the power on / off, depress the white button and rotate the
Rheostat.
• Do not allow liquid to seep into the Handle heads, Ophthalmoscope, Otoscope heads and the
Laryngeal stems.
• Reusable speculums, Mirrors and Tongue Depressors can be washed with soapy water and thor-
oughly dried.
• Allow bulbs to cool down before replacing.
