11
Table 3-2
Safety Instructions for ECG Monitoring
M Use the same type electrode on a patient. If skin rash or other unusual symptom occurs, remove electrodes
from patient. Do not attach electrodes on the patient with an inflammation of the skin or scores on skin.
% Gima Vital Pro Monitor can only be equipped with ECG leads provided by our company; using ECG leads
supplied by other companies may cause improper performance or poor protection while using defibrillator.
% Electric parts of electrodes, leads and cable are forbidden to contact any other conductive parts (including
ground).
% Gima Vital Pro Monitor can resist against defibrillator and electro-surgical unit. Readings may be inaccurate
for a short time after or during using defibrillator or electro-surgical unit.
% Transient caused by cable circuitry blocks while monitoring may be similar to the real heartbeat waveform, as
a result resistance heart rate alarm rings. If you put the electrodes and cable in proper places according to this
manual’s instructions and the instructions for using electrode, the chance of this transient occurring will be
decreased.
M Besides the improper connection with electro-surgical unit may cause burns, the monitor may be damaged or
arouse deviations of measurement. You can take some steps to avoid this situation, such as do NOT use small
Lead connection 1
（
IEC standard
）
Lead connection 2
（
AHA standard
）
Electrode placement
Color
Electrode
label
Color
Electrode
label
Red
R
White
RA
Place on the right arm, or the intersection between the
centerline of the right clavicle and Rib 2
Yellow
L
Black
LA
Place on the left arm, or the intersection between the
centerline of the left clavicle and Rib 2
Green
F
Red
LL
Place on the left leg, or left part of the upper abdomen
Black
N or RF
Green
RL
Place on the right leg, or right part of the upper abdomen
White
C
Brown
V
An individual and movable electrode pasted on the chest
White or Red
C1
Brown
V1
On the 4
th
intercostal space at right border of sternum
White or Yellow
C2
Brown or
Yellow
V2
On the 4
th
intercostal space at left border of sternum
White or Green
C3
Brown or
green
V3
The middle line between V2 and V4
White or brown
(Blue)
C4
Brown or
blue
V4
The intersection between the centerline of the clavicle and
the 5
th
intercostal
White or Black
C5
Brown or Red
V5
The intersection between the left anterior axillary line and
the horizontal level of V4
White or Purple
C6
Brown or
purple
V6
The intersection between the left mid-axillary line and the
horizontal level of V4
