Gima PC-900 - 6.2 TEMP Monitoring; 6.3 NIBP Monitoring; 6.4 SpO2 Monitoring; 6.5 Pulse Rate monitoring

46
6.2 TEMP Monitoring
1. TEMP measuring range: 21.0℃~50.0℃
2. TEMP measuring accuracy: not greater than 0.2 ℃ for TEMP measuring range from 25.0
o
C~45.0 ℃
3. TEMP responding time: ≤150s for KRK sensor; ≤40s for YSI sensor
6.3 NIBP Monitoring
1. Measuring method: Oscillometric Technique
2. Pneumatic pressure measuring range: 0 mmHg~300mmHg
3. Accuracy of pressure measurement: ±3 mmHg
4. Cuff inflation time: <10 seconds (typical adult cuff)
5. Average measurement time: < 90 seconds
6. Air release time while the measurement is canceled: ≤2 seconds (typical adult cuff)
7. Initial cuff inflation pressure
Adult: 175 mmHg pediatric: 135 mmHg Neonate: 65 mmHg
8. Overpressure protection limit
Adult: ≤ 300 mmHg pediatric: ≤ 240mmHg Neonate: ≤ 150 mmHg
9. NIBP measurement range:
press（unit）
Adult
Pediatric
Neonate
SYS
mmHg
40~275
40~200
40~135
MAP
mmHg
20~230
20~165
20~110
DIA
mmHg
10~210
10~150
10~95
10. NIBP measurement accuracy:
Maximal mean difference: ±5 mmH
g
Maximal standard deviation: 8 mmHg
Measurement mode: Manual, Auto, STAT
6.4 SpO
2
Monitoring
1. Transducer: dual-wavelength LED
Wavelength: Red light: 663 nm, Infrared light: 890 nm.
Maximal optical output power: less than 2mW maximum average
2. SpO
2
measuring range: 35%~100%
3. SpO
2
measuring accuracy: Arms is not greater than 3% for SpO
2
range from 70% to 100%
*NOTE: Arms is the accuracy defined as root-mean-square value of deviation according to ISO 80604-2-61
4
. Low perfusion performance: the declared accuracy is attained when the pulse amplitude modulation ratio is as
low as 0.4%.
6.5 Pulse Rate monitoring
1. Pulse rate measuring range: 30bpm~240bpm
2. Pulse rate measuring accuracy: ±2bpm or ±2%, whichever is greater.
6.6 Data Recording
1. Sensitivity selection tolerance: ±5%
2. Recording speed: 25mm/s
3. Recording speed accuracy: ±10%
