Removing the Battery from the Bike
A. Loosen the quick-release from the seat and lift seat from the seat post.
B. Turn the key to release the locking pin.
C. Slide out battery from its position in the bike.
SECTION 8: Specific Operating Instructions
A battery meter is located on the top of the battery which shows the charge if you press the button next
to the battery meter. Note, fully charged battery will show 4 RED LED lights color and empty battery will
show 1 RED LED light.
To ride your bike electrically, handlebar display must be ON. Always make sure it is at full charge when
you begin to ride your bike.
On the right handlebar is the throttle. You can start your bike by pedaling or by twisting the throttle. As
you pedal, the motor will automatically help you if the display is in the ON position.
