Scooter & Control Diagrams
Scooter Diagram
1 Mirrors
12
Floor board
2 Throttle
13
VIN
3 Brake Lever
14
Seat
4 Headlight & Turn Signal Lights
15
Rear wheel
5 Front mudguard
16
Motor & Rear Brake (internal)
6 Front Fork
17
Rear suspension
7 Brakes
18
Rear mudguard
8 Front wheel
19
Side reflector
9 Chassis guard board
20
Rear Turn Signal Lights
10 Middle stand
21
Back rest
11 Pedal
8
