System 3000
Blind timer and timer Display
Saving the ventilation position
To save and execute the ventilation position, the Venetian blind/shutter must be moved to the
upper end position until the flashing arrow switches off automatically.
￭ From the top end position press and hold down Ɵ.
The blind/shutter moves in the lower end position direction.
￭ Additionally press ƞ and hold it down.
The blind/shutter remains stopped, but continues to move after 4 seconds.
￭ As soon as the desired ventilation position has been reached, release both sensor but-
tons and press the ƞ button within the next 4 seconds.
The ventilation position is saved. The blind/shutter moves back to the upper end position.
If the ventilation position is saved again, the old value is overwritten.
6 Operation of lighting
Switch light
￭ Press button ƞ or Ɵ for less than 0.4 seconds.
With a dimming insert, the light switches to the brightness that was last set or a saved
brightness.
Switch light on with minimum brightness
￭ Press Ɵ for longer than 0.4 seconds.
Adjust the brightness
￭ Press ƞ or Ɵ for longer than 0.4 seconds.
Save switch-on brightness
￭ Adjust the brightness
￭ Press ƞ and Ɵ for longer than 4 seconds.
Switch-on brightness is saved.
For confirmation, the light is switched off briefly and switched on again.
Delete switch-on brightness
￭ Press Ɵ or ƞ briefly: light switches on at the saved switch-on brightness.
￭ Press ƞ and Ɵ for longer than 4 seconds.
The switch-on brightness has been deleted.
Switching on takes place at the last brightness value set.
For confirmation, the light is switched off briefly and switched on again.
7 Activate functions
Automatic operation/manual operation
Pressing Ƙ toggles between automatic operation and manual operation.
If all switching times are deactivated, the cover switches automatically to manual opera-
tion. Automatic mode cannot be activated.
Figure2: Automatic mode with Venetian blind or switching/dimming insert
4 / 10
32596512 10865949 10.07.2018
