Page 9
ELECTRAMATE
2000
1.0 DESIGN
1.2 TECHNICAL DATA
It is easier if all pipes terminate vertically in the
positions shown opposite. Compression or
push fit connections can be used and we do
offer a set of flexible connectors as an option.
All pipe positions are approximate and subject
to a tolerance of ± 10mm in any direction.
litres/sec
Performance Graph of Grundfos 15/50 Pump
