Global Laser LaserLyte L Series - Page 10

F) Mounting Brackets
16mm
30mm
50mm
25 mm (center of holes)
50 mm
100mm
B4 BRACKET
16mm
25mm
B2 BRACKET
150mm
25mm
16mm
B6 BRACKET
Drawings not to scale
ISO9001 Certied
9090-02-070 Rev 3 18/12/2015
B12 BRACKET
16mm
30mm
