E) Heavy Duty Mounting Clamp
SIDE VIEW
Grub Screw B (M3)
TOP VIEW
Grub Screw A (M3)
32.00
14.00
Ø30.00
BOTTOM
SECTION
SIDE VIEW
2 Holes Tap M3 x 8 Deep
Tap M5 x 8 Deep
BOTTOM SECTION
BOTTOM VIEW
2 Holes Drill 3.2Ø & C/Bored 6.00Ø x
3.5 Deep
1 Hole Drill 4.2Ø & C/Bore 7.5Ø x 5 Deep at One End
and Tap M5 x 8 Deep at The Other End
BOTTOM SECTION
TOP VIEW
C) Magnetic Base
D) MK1 Mounting Clamp
30.00
Ø35.00
FRONT VIEW
6.00
M6 Stud
32.50
64.00
6.35
24.70
12.70
6x32 unc 5/8”
Phillips screw and
6x32 unc hex nut
(Philips screw A)
M5 Nut
M5 x 25/35 C/sk
socket screw
(Machine Screw A)
12.70
SIDE VIEW
FRONT VIEW
