Global Laser LaserLyte L Series User Manual

4. Summary Of Projections
5. Mounting
To ensure the lifetime and the stability of the laser it is recommended that it is mounted in a
suitable heat sink/mount. The case temperature should be kept within the specied range at all
times failure to do this could result in shortened lifetime or catastrophic failure. As a guide, laser
diode lifetime decreases by a factor of two (approx) for every ten degree increase in operating
temperature.
There are two mounting clamps available as stranded from Global Laser for the LaserLyte L
Series.
Global laser’s MK1 mounting kit provides a cost eect mounting solution; the laser clamp rotates
horizontally through 360° and vertically through 180° and the mounting post allows vertical
movement. The mounting clamp is compatible with Global Laser’s mounting brackets and is
supplied with two dierent lengths of machine screws to increase the range of mounting
surfaces which can be utilised.
Part Number Wavelength Diode Power Projection Fan Angle
L5D 650nm 1mW Dot N/A
L3D 635nm 1mW Dot N/A
L5SL 650nm 5mW Short Line 53°
L3SL 635nm 5mW Short Line 53°
L10 SL 635nm 10mW Short Line 53°
L15 SL 635nm 15mW Short Line 53°
L5ML 650nm 5mW Medium Line 65°
L3ML 635nm 5mW Medium Line 65°
L10 M L 635nm 10mW Medium Line 65°
L15 ML 635nm 15mW Medium Line 65°
L5LL 650nm 5mW Long Line with Centre Dot 90°
L3LL 635nm 5mW Long Line with Centre Dot 90°
L10 L L 635nm 10mW Long Line with Centre Dot 90°
L15 LL 635nm 15mW Long Line with Centre Dot 90°
L5CL 650nm 5mW Crossed Lines 30°
L3CL 635nm 5mW Crossed Lines 30°
L10 CL 635nm 10mW Crossed Lines 30°
L15 CL 635nm 15mW Crossed Lines 30°
