Global Skyware 9013 - Elevation Chart

9
ELEVATION IN DEGREES
Use of Elevaon Chart
(1) Determine = the dierence between your site longitude and the satellite longitude.
(2) Find your latude on horizontal axis.
(3) Follow your latude up unl you intersect the curve for your .
(4) Read Elevaon value on vercal axis.
EARTH STATION LATITUDE IN DEGREES NORTH OR SOUTH OF EQUATOR
3.1 ELEVATION CHART
