6
Terminals
The input/output terminals are located on the side of the mounting bracket
next to the inverter.
1-
Reset
2-
O/S/C
3-
Stop
4-
Close
5-
Ped
6-
Safety
7-
Common (for terminals 1 to 5 only) *Refer below
8-
+24V DC for accessories
9-
0V DC for accessories
10-
+24V DC for flashing light
11-
0V DC for flashing light
*IMPORTANT- Do NOT use terminal 7 (Common) to power accessories.
Terminal 6 is the common for terminals 1 to 5. Terminal 9 (0V DC) is the
common for 24V DC accessories.
A closed contact between terminal 2 (O/S/C) and terminal 6 (common) will open and
close the gate depending on chosen logic.
A closed contact between terminal 5 (Pedestrian) and terminal 7 (common) will open
the gate to the percentage set at parameter n13. Pedestrian mode is auto close only.
Stop devices are linked in series through terminals 3 and 7 (common). If no stop
devices are present terminal 3 must be linked to terminal 7.
A closed contact between terminals 4 (Close) and 7 (common) will close the gate
Safety devices are linked in series through terminals 6 (Safety) and 7 (common).
Safety devices must be fitted.
