Attaching the plumbing
a. Use the PVC fitting in bag four from the hardware kit to hookup the plumbing in the upper
ladder
b. Add PTFE (Teflon) tape and then PTFE (Teflon) glue to the to the 1” MPT Adapter to ensure the
plumbing doesn’t leak
c. Through the access hole located at the top of the upper ladder, thread fitting into the internal
brass fitting (molded into the upper ladder portion of the slide)
d. Apply PVC primer to the female end of the adapter and to one end of the flex hose
e. Starting with the primed end of the flex hose, route the flex hose through the upper ladder
portion of the slide, start at the 5” hole located at the bottom of the upper ladder
f. Apply PVC glue to the female end of the adapter and the flex hose where it was primed
g. Join the flex hose with the PVC adapter (push in and twist for good adhesion) until the pipe
bottoms out, hold them together until they have started to bond
h. Allow for proper drying time before moving to the next step
