Installing the dual seal on the upper ladder
a. Measure the center of the ladder, use the two through bolt holes as measuring points, mark
center with a sharpie
b. Install the longer 54” foam-rubber gasket from the seal kit tube on the ladder, start at the top
and install it following the curve, cut off any excess and discard it, each end should be roughly 3”
from the flume tops
c. From the roll of butyl, cut two pieces 32” long, take the exposed sides of the butyl and attach
them to double the thickness, peel one side of the paper off and mark the center with your
thumbnail
d. Line the center of the ladder to the center of the doubled 32” piece of butyl (paper side facing
you), place it directly under the foam-rubber gasket following the curve, make sure they are
touching to ensure proper placement
e. Firmly press in the butyl to ensure it is secure to the ladder, then remove the paper backing from
the butyl
Through bolt holes to find center
