1. Place the assembled slide on the pool deck relative to the pool wall with the ladder side over the
stub up location.
2. Check to ensure the exit of the flume clears all coping edges. The slide may be angled to your
preference as long as the guidelines provided in Global Pool Product’s Placement Instructions are
followed.
3. Once the slide is in its desired location and all guidelines are met use a center punch or other
marking tool to indicate the mounting holes on the ladder and pedestal so marks are visible on the
pool deck surface.
4. Remove the slide and any other objects that could obstruct the drilling of the anchor holes.
5. Using a Hammer Drill equipped with a ½” (13mm) SDS concrete bit, drill the marked holes to a depth
of 3” (76mm). Note: Mark the 3” depth on your SDS bit with some tape to prevent drilling anchor
holes too deep. Ensure you are drilling the holes straight and perpendicular for proper holding and
strength of anchor.
6. Clear all anchor holes from any debris. Shop vac may be required if any debris gets in anchor holes.
7. Place slide back over anchor holes and assemble anchors with the included washer and nut so the so
the top of the nut is flush with the anchor.
8. Plumb the slide to stub up location.
a. Clean flex hose from slide and stub-up plumbing prior to assembling.
b. Use PVC Primer & PVC Glue to adhere plumbing components from the slide and stub-up
plumbing together.
