11 Servicing
Diagram 11.8
9949
SEAL
FRONT
CASING
PANEL
INNER
CASING
PANEL
Diagram 11.7
MIN.
MAX.
POTENTIOMETERS
RETAINING
LATCHES
11407
SERVICE
POTENTIOMETER
11417
CONTROLS
FASCIA
USER
INTERFACE
11.7 Inner Casing Panel Seal Check.
Refer to diagram 11.8.
Check the condition of the seal, replace as required.
To replace remove the old seal, thoroughly clean the casing
surfaces. Fit the new seal, it is supplied to the correct length.
Diagram 11.6
12853
FLUE ELBOW
COMBUSTION
ANALYSER
TEST POINT
FLUE DUCT
EXTENSION
